Proximity Switches w/ Background Suppression

Proximity switch with background suppression, M18, 120mm, bgs, PNP complementary, plug M12 4 pins

Proximity switch with background suppression, M18, PNP complemantary cable, 600 Hz, 120 mm, Proximity switch with background su

Label fork sensor, fork width 5 mm, teach-in, PNP output, plug M8 4-pin

Optical window, metal housing, fork width 40 mm, fork depth 80 mm, infrared LED, plug M8, 3-pin

Fork Sensor, fork width 80 mm, smallest part to detect 0.4 mm switching frequency up to 1500 Hz, robust metal housing, NO/NC sw

Fork Sensor, fork width 50 mm, smallest part to detect 0.4 mm switching frequency 1500Hz, robust metal housing, NO/NC switchabl

Fork Sensor, metal housing, fork width 30 mm, fork depth 34 mm, red light, 1500 Hz, metal plug M8, 3-pin

Fork Sensor, metal housing, fork width 20 mm, fork depth 24 mm, red light, 1500 Hz, metal plug M8, 3-pin

Diffuse sensor with background suppression, 120 ... 600 mm, laser (class 1), 2xQ, Auto-detect, Teach-in, Display, IP 67 / IP 69

Diffuse sensor with background suppression, 200 ... 1000 mm, laser (class 1), 2xQ, Auto-detect, Teach-in, Display, IP 67 / IP 6

Description
Stable processes thanks to intelligent color detection, regardless of distance
Economical solutions through up to twelve storable colors or jobs
Dependable switching behaviour through reliable glare suppression (depending on model)
Intuitive sensor setup with integrated LCD display
Customised adjustment to applications through digital color value output using IO-Link

Product data:
Velocity [Hz]: 3000
Amount of colors: 7
Sensor principle: Color sensor
Spot size [mm]: 8 x 8
Series: F55 (50 x 50,1 x 23 mm)
Working distance min. [mm]: 20
Working distance max. [mm]: 150
Interface: IO-Link
Light source: LED, white
Switching output: PNP/NPN (auto detect)
Temperature range [°C]: -10 ... +55
Connection type: Metal plug M12, 5-pin
Enclosure rating: IP 67, IP69

Description
Stable processes thanks to intelligent color detection, regardless of distance
Economical solutions through up to twelve storable colors or jobs
Dependable switching behaviour through reliable glare suppression (depending on model)
Intuitive sensor setup with integrated LCD display
Customised adjustment to applications through digital color value output using IO-Link

Product data:
Velocity [Hz]: 3000
Amount of colors: 12
Sensor principle: Color sensor
Spot size [mm]: 8 x 8
Series: F55 (50 x 50,1 x 23 mm)
Working distance min. [mm]: 20
Working distance max. [mm]: 150
Light source: LED, white
Switching output: PNP/NPN (auto detect)
Temperature range [°C]: -10 ... +55
Connection type: Metal plug M12, 8-pin
Enclosure rating: IP 67, IP69

Description
Stable processes thanks to intelligent color detection, regardless of distance
Economical solutions through up to twelve storable colors or jobs
Dependable switching behaviour through reliable glare suppression (depending on model)
Intuitive sensor setup with integrated LCD display
Customised adjustment to applications through digital color value output using IO-Link

Product data:
Velocity [Hz]: 3000
Amount of colors: 1
Sensor principle: Color sensor
Spot size [mm]: 4 x 4 @ 40 mm
Series: F55 (50 x 50,1 x 23 mm)
Working distance min. [mm]: 18
Working distance max. [mm]: 60
Interface: IO-Link
Light source: LED, white
Switching output: PNP/NPN (auto detect)
Temperature range [°C]: -10 ... +55
Connection type: Metal plug M12, 4-pin
Enclosure rating: IP 67, IP69

Description
Stable processes thanks to intelligent color detection, regardless of distance
Economical solutions through up to twelve storable colors or jobs
Dependable switching behaviour through reliable glare suppression (depending on model)
Intuitive sensor setup with integrated LCD display
Customised adjustment to applications through digital color value output using IO-Link

Product data:
Velocity [Hz]: 3000
Amount of colors: 7
Sensor principle: Color sensor
Spot size [mm]: 4 x 4 @ 40 mm
Series: F55 (50 x 50,1 x 23 mm)
Working distance min. [mm]: 18
Working distance max. [mm]: 60
Interface: IO-Link
Light source: LED, white
Switching output: PNP/NPN (auto detect)
Temperature range [°C]: -10 ... +55
Connection type: Metal plug M12, 5-pin
Enclosure rating: IP 67, IP69

Description
Stable processes thanks to intelligent color detection, regardless of distance
Economical solutions through up to twelve storable colors or jobs
Dependable switching behaviour through reliable glare suppression (depending on model)
Intuitive sensor setup with integrated LCD display
Customised adjustment to applications through digital color value output using IO-

Product data:
Velocity [Hz]: 3000
Amount of colors: 12
Sensor principle: Color sensor
Spot size [mm]: 4 x 4 @ 40 mm
Series: F55 (50 x 50,1 x 23 mm)
Working distance min. [mm]: 18
Working distance max. [mm]: 60
Light source: LED, white
Switching output: PNP/NPN (auto detect)
Temperature range [°C]: -10 ... +55
Connection type: Metal plug M12, 8-pin
Enclosure rating: IP 67, IP69

Description
Stable processes thanks to intelligent color detection, regardless of distance
Economical solutions through up to twelve storable colors or jobs
Dependable switching behaviour through reliable glare suppression (depending on model)
Intuitive sensor setup with integrated LCD display
Customised adjustment to applications through digital color value output using IO-Link

Product data:
Velocity [Hz]: 500
Amount of colors: 7
Sensor principle: Color sensor
Spot size [mm]: 6 x 6
Series: F55 (50 x 50,1 x 23 mm)
Working distance min. [mm]: 18
Working distance max. [mm]: 32
Interface: IO-Link
Light source: LED, white
Switching output: PNP/NPN (auto detect)
Temperature range [°C]: -10 ... +55
Connection type: Metal plug M12, 5-pin
Enclosure rating: IP 67, IP69

Photoelectric diffuse sensor,s with background suppression, blue light, robust against environmental influences, NPN, IP67 plug

Photoelectric diffuse sensor,s with background suppression, blue light, robust against environmental influences, PNP, IP67 plug

Laser distance sensor, working distance 200…1000 mm, 2xQ, 4…20mA / 0.1...10V, RS485, laser class 1, Autodetect (PNP/NPN), metal

Laser distance sensor, working range 200…1000 mm, 2xQ, QA 4…20 mA / 0.1...10 V, IO-Link, laser class 1, auto-detect (PNP/NPN),

Laser distance sensor, working distance 120…600 mm, 2xQ, QA 4…20mA / 0.1...10V, RS485, laser class 1, Autodetect (PNP/NPN), met
