Photoelectric sensors

20 … 700 mm, 2 x NPN antivalent, red light, bgs, plug M12 5-pin This product is in discontinuation. Last orders until: 19 Dece

20 … 700 mm, 2 x PNP antivalent, red light, bgs, plug M12 5-pin This product is in discontinuation. Last orders until: 19 Dece

Proximity switch with background suppression 12-240 V AC/DC, 20-700mm, 25Hz, red light

Diffuse sensor with background suppression, 120 ... 600 mm, laser (class 1), 2xQ, Auto-detect, Teach-in, Display, IP 67 / IP 69

Diffuse sensor with background suppression, 200 ... 1000 mm, laser (class 1), 2xQ, Auto-detect, Teach-in, Display, IP 67 / IP 6

Distance sensor with time-of-flight measurement, reflector, 0.3...70 m, laser, analogue 4...20 mA, auto-detect, N.O./N.C., teac

Description
Stable processes thanks to intelligent color detection, regardless of distance
Economical solutions through up to twelve storable colors or jobs
Dependable switching behaviour through reliable glare suppression (depending on model)
Intuitive sensor setup with integrated LCD display
Customised adjustment to applications through digital color value output using IO-Link

Product data:
Velocity [Hz]: 3000
Amount of colors: 7
Sensor principle: Color sensor
Spot size [mm]: 8 x 8
Series: F55 (50 x 50,1 x 23 mm)
Working distance min. [mm]: 20
Working distance max. [mm]: 150
Interface: IO-Link
Light source: LED, white
Switching output: PNP/NPN (auto detect)
Temperature range [°C]: -10 ... +55
Connection type: Metal plug M12, 5-pin
Enclosure rating: IP 67, IP69

Description
Stable processes thanks to intelligent color detection, regardless of distance
Economical solutions through up to twelve storable colors or jobs
Dependable switching behaviour through reliable glare suppression (depending on model)
Intuitive sensor setup with integrated LCD display
Customised adjustment to applications through digital color value output using IO-Link

Product data:
Velocity [Hz]: 3000
Amount of colors: 12
Sensor principle: Color sensor
Spot size [mm]: 8 x 8
Series: F55 (50 x 50,1 x 23 mm)
Working distance min. [mm]: 20
Working distance max. [mm]: 150
Light source: LED, white
Switching output: PNP/NPN (auto detect)
Temperature range [°C]: -10 ... +55
Connection type: Metal plug M12, 8-pin
Enclosure rating: IP 67, IP69

Description
Stable processes thanks to intelligent color detection, regardless of distance
Economical solutions through up to twelve storable colors or jobs
Dependable switching behaviour through reliable glare suppression (depending on model)
Intuitive sensor setup with integrated LCD display
Customised adjustment to applications through digital color value output using IO-Link

Product data:
Velocity [Hz]: 3000
Amount of colors: 1
Sensor principle: Color sensor
Spot size [mm]: 4 x 4 @ 40 mm
Series: F55 (50 x 50,1 x 23 mm)
Working distance min. [mm]: 18
Working distance max. [mm]: 60
Interface: IO-Link
Light source: LED, white
Switching output: PNP/NPN (auto detect)
Temperature range [°C]: -10 ... +55
Connection type: Metal plug M12, 4-pin
Enclosure rating: IP 67, IP69

Description
Stable processes thanks to intelligent color detection, regardless of distance
Economical solutions through up to twelve storable colors or jobs
Dependable switching behaviour through reliable glare suppression (depending on model)
Intuitive sensor setup with integrated LCD display
Customised adjustment to applications through digital color value output using IO-Link

Product data:
Velocity [Hz]: 3000
Amount of colors: 7
Sensor principle: Color sensor
Spot size [mm]: 4 x 4 @ 40 mm
Series: F55 (50 x 50,1 x 23 mm)
Working distance min. [mm]: 18
Working distance max. [mm]: 60
Interface: IO-Link
Light source: LED, white
Switching output: PNP/NPN (auto detect)
Temperature range [°C]: -10 ... +55
Connection type: Metal plug M12, 5-pin
Enclosure rating: IP 67, IP69

Description
Stable processes thanks to intelligent color detection, regardless of distance
Economical solutions through up to twelve storable colors or jobs
Dependable switching behaviour through reliable glare suppression (depending on model)
Intuitive sensor setup with integrated LCD display
Customised adjustment to applications through digital color value output using IO-

Product data:
Velocity [Hz]: 3000
Amount of colors: 12
Sensor principle: Color sensor
Spot size [mm]: 4 x 4 @ 40 mm
Series: F55 (50 x 50,1 x 23 mm)
Working distance min. [mm]: 18
Working distance max. [mm]: 60
Light source: LED, white
Switching output: PNP/NPN (auto detect)
Temperature range [°C]: -10 ... +55
Connection type: Metal plug M12, 8-pin
Enclosure rating: IP 67, IP69

Description
Stable processes thanks to intelligent color detection, regardless of distance
Economical solutions through up to twelve storable colors or jobs
Dependable switching behaviour through reliable glare suppression (depending on model)
Intuitive sensor setup with integrated LCD display
Customised adjustment to applications through digital color value output using IO-Link

Product data:
Velocity [Hz]: 500
Amount of colors: 7
Sensor principle: Color sensor
Spot size [mm]: 6 x 6
Series: F55 (50 x 50,1 x 23 mm)
Working distance min. [mm]: 18
Working distance max. [mm]: 32
Interface: IO-Link
Light source: LED, white
Switching output: PNP/NPN (auto detect)
Temperature range [°C]: -10 ... +55
Connection type: Metal plug M12, 5-pin
Enclosure rating: IP 67, IP69

Photoelectric diffuse sensor,s with background suppression, blue light, robust against environmental influences, NPN, IP67 plug

Photoelectric diffuse sensor,s with background suppression, blue light, robust against environmental influences, PNP, IP67 plug

Laser distance sensor, working distance 200…1000 mm, 2xQ, 4…20mA / 0.1...10V, RS485, laser class 1, Autodetect (PNP/NPN), metal

Laser distance sensor, working range 200…1000 mm, 2xQ, QA 4…20 mA / 0.1...10 V, IO-Link, laser class 1, auto-detect (PNP/NPN),

Laser distance sensor, working distance 120…600 mm, 2xQ, QA 4…20mA / 0.1...10V, RS485, laser class 1, Autodetect (PNP/NPN), met

Laser distance sensor, working range 120…600 mm, 2xQ, QA 4…20 mA / 0.1...10 V, IO-Link, laser class 1, auto-detect (PNP/NPN), m

Distance sensor with time-of-flight measurement, button, 0.1...5 m, laser, analogue 0...10 V, auto-detect, N.O./N.C., teach-in,

Distance sensor with time-of-flight measurement, button, 0.1...5 m, laser, analogue 4...20 mA, auto-detect, N.O./N.C., teach-in

Distance sensor with time-of-flight measurement, button, 0.06...5 m, laser, measured value output via IO-Link, 2x auto-detect,
