SENSOPART FT 25-RLH-PS-M3M

SensoPart FT 25-RLH-PS-M3M — For this prodcut a new version is available: 609-11019 FT 25-RLH-PNSL-M3M That offers additional functionality via IO-Link. Mor. Genuine product, supplied and supported by ZTEC.

0,00 € 0,00 €
kr 0,00
(eksklusiv moms)
OFFICIAL SENSOPART PARTNER · ZTECCE · EU compliant

SensoPart FT 25-RLH-PS-M3M

A photoelectric proximity sensor with background suppression — it detects an object at a defined range and reliably ignores whatever is behind it

Order code
FT 25-RLH-PS-M3M
Order number
609-11007
SensoPart FT 25-RLH-PS-M3M
Working distance
4
Output
PNP
Connection
Metal plug M8, 3-pin
Protection
IP69K

SensoPart FT 25-RLH-PS-M3M is a photoelectric proximity sensor with background suppression — it detects an object at a defined range and reliably ignores whatever is behind it, supplied and supported by ZTEC as your SensoPart partner in the Nordics and Baltics.

Key features

Precisely adjustable background suppression
Reliable switching despite varying object colours and surfaces
Reliable operation even with highly reflective backgrounds, thanks to SensoPart ASIC technology
Particularly suitable for the detection of the smallest of objects
Simple alignment thanks to easily visible light spot
Robust glass-fibre-reinforced plastic housings

Applications & Industries

What you can solve with this product:

Typical industries: Factory automationMachineryPackagingFood & beverage
Presence and completeness inspection
Presence and completeness inspection
Measurement and positioning
Measurement and positioning
Surface and print/label inspection
Surface and print/label inspection
Robot guidance and pick-and-place
Robot guidance and pick-and-place

Specifications

Optical data
AdjustmentTeach-in
Working distance min. [mm]
Working distance max. [mm]
Light sourceLaser, red (Class 1)
Electrical data
Switching output
Velocity [Hz]1000
Mechanical data
Enclosure ratingIP69K
SeriesF25 (34 x 20 x 12 mm)
Temperature range [°C]-20 ... +60
Connection typeMetal plug M8, 3-pin
Additional specifications
Sensor principlePhotoelectric diffuse sensor with Background Suppression
