Hikrobot MVL-AF2045M-M42
607.87 €
607.87 €
kr 4,543.61
(Tax excluded)
OFFICIAL HIKROBOT PARTNERCE · EU compliant
Hikrobot MVL-AF2045M-M42
FA Lens
Order code
MVL-AF2045M-M42
Order number
102203107
Working distance
150 mm to 999 mm
Focal length
20 mm
Hikrobot MVL-AF2045M-M42 is an industrial machine-vision lens — sharp, low-distortion imaging for inspection and measurement.
Key features
✓Provides excellent consistency of image clarity.
✓Provides low distortion.
✓Provides max. image size Φ30 mm for APS-C area scan and 4k 7 μm line scan cameras.
Applications & Industries
What you can solve with this product:
Typical industries: PackagingPrinting
Specifications
Performance
Focal length20 mm
F-numberF4.5 to C
Image sizeΦ30 mm
Optical distortion0.20%
Magnification range0.02 x to 0.134 x
Working distance range150 mm to 999 mm
Mechanical
Iris controlManual
Focus controlManual
Filter threadM43 × 0.75
MountM42 × P1
Flange back length12 mm
DimensionΦ52.7 mm × 51.4 mm (Φ2.1" × 2.0")
Weight243 g (0.5 Ib.)
Temperature–10 °C to 50 °C (14 °F to 122 °F)
General
CertificationRoHS 2.0
