Hikrobot MVL-LF6040M-0168V-M72
FA Lens
Order code
MVL-LF6040M-0168V-M72
Order number
102204094
Working distance
945 mm to 345 mm (tolerance: ±5 mm)
Focal length
60 mm
Hikrobot MVL-LF6040M-0168V-M72 is an industrial machine-vision lens — sharp, low-distortion imaging for inspection and measurement.
Key features
✓Adopts high-precision lens for 8k 7 μm line scan cameras.
✓Provides excellent picture sharpness consistency, large aperture, and low distortion.
✓Provides superior resolution at maximum aperture of F4.
✓Provides maximum image size Φ60 mm.
Applications & Industries
What you can solve with this product:
Specifications
Performance
Focal length60 mm
F-numberF4.0 to F22
Image sizeΦ60 mm
Optical distortion0.14%
Magnification range0.067 x to 0.2 x
Working distance range945 mm to 345 mm (tolerance: ±5 mm)
Mechanical
Iris controlManual
Focus controlManual
Filter threadM39 × P0.5
MountM72 × P0.75
Flange back length12 mm
DimensionΦ75 mm × 72.8 mm to 80.8 mm (Φ3" × 2.9" to 3.2")
Temperature–10 °C to 50°C (14 °F to 122 °F)
General
CertificationRoHS 2.0
