LRS-150F-24

Hikrobot LRS-150F-24 — Genuine Hikrobot Cables — cable for machine-vision cameras, lighting and peripherals. Genuine product, supplied by ZTEC.

176.82 € 176.82 €
kr 1,321.80
(Tax excluded)
Contact Us
Documents
LRS-150F-24 - Datasheet.pdf
OFFICIAL HIKROBOT PARTNERCE · EU compliant

Hikrobot LRS-150F-24

Cable

Order code
LRS-150F-24
Order number
310100904

Genuine Hikrobot Cables — cable for machine-vision cameras, lighting and peripherals.

Key features

✓The industrial power supply adopts terminal blocks as connectors, and can be used to power the device. Multiple specifications are available.

Specifications

Electrical specification
Input voltage range85 VAC ~ 264 VAC 125 VDC ~ 375 VDC
Output power150 W max
Output voltage24 V
Output current0 A ~ 6.25 A
protection
Over voltage protectionOvervoltage protection range: 28.8 V to 33.6 V Protected mode: Turn off the output voltage, restart and restore.
protection
MTBF700,000 h (Standard: Telcordia SR-332)
Additional information
Working temperature–10 °C to 70 °C (14 °F to 158 °F) (For temperatures above 50 °C, the output load decreases by 2.5% for every degree increase in temperature.)
CertificationCE,UL,CCC,SIQ
Additional specifications
End A connectorTerminal block (220 VAC/DC Input)
End B connectorTerminal block
Applicable scenarioStatic
Input AC current1.7 A @ 115 VAC 1 A @ 230 VAC
Over current protection> 120% of rated current, hiccup mode
PackagingIndividual package

Downloads

Datasheets, drawings and manuals — all in one place.

LRS-150F-24 - Datasheet.pdfPDF · 477.5 KB
