Hikrobot MV-ACCL-SDR-MDR-HF-3m

Hikrobot MV-ACCL-SDR-MDR-HF-3m

Hikrobot CameraLink Cable（MDR to SDR）. Flexible Camera Link Cable, S2M, Straight, 3m, moveable
295.20 € 295.20 €
kr 2,206.57
(Tax excluded)
Contact Us
OFFICIAL HIKROBOT PARTNERCE · EU compliant

Hikrobot MV-ACCL-SDR-MDR-HF-3m

Cable

Order code
MV-ACCL-SDR-MDR-HF-3m
Order number
310100991

Genuine Hikrobot Cables — cable for machine-vision cameras, lighting and peripherals.

Key features

✓The Camera Link Flex Data Cable can be used for data transmission of Camera Link interface cameras, and is available in a variety of lengths.

Specifications

Specifications
End A connectorSDR26
End B connectorMDR26
Cable diameter9.5 mm
Length3 m
Cable mechanicalUL20276
JacketPVC
Cable colorBlack
Connector modelmade in China
Connector durability500 cycles
Min. bending radius114 mm
Applicable scenarioDrag chain
Max. U-type bending cycles5 million times
Max. voltage30 VDC
Working temperature-20°C~80°C
CertificationUL
PackagingIndividual package
