Hikrobot MVL-AF2524M-M42

Hikrobot MVL-AF2524M-M42

Hikrobot MVL-AF2524M-M42 — An industrial machine-vision lens — sharp, low-distortion imaging for inspection and measurement. Genuine product, supplied by ZTEC.

576.65 € 576.65 €
kr 4,310.75
(Tax excluded)
Contact Us
OFFICIAL HIKROBOT PARTNERCE · EU compliant

Hikrobot MVL-AF2524M-M42

FA Lens

Order code
MVL-AF2524M-M42
Order number
310101826
Working distance
150 mm to inf mm
Focal length
25 mm

Hikrobot MVL-AF2524M-M42 is an industrial machine-vision lens — sharp, low-distortion imaging for inspection and measurement, supplied and supported by ZTEC as your Hikrobot partner in the Nordics and Baltics.

Key features

✓Adopts high-precision lens for 4k 7 μm line scan cameras.
✓Provides excellent consistency of image clarity, large aperture, and low distortion.
✓Provides ultra-high resolution at the max. aperture of F2.4.
✓Provides max. image size Φ29 mm.

Applications & Industries

What you can solve with this product:

Sharp, distortion-free imaging
Sharp, distortion-free imaging for inspection and gauging
Matched field of view and working distance
Matched field of view and working distance for the camera
Stable imaging
Stable imaging for measurement and positioning

Specifications

Performance
Focal length25 mm
F-numberF2.4 to F16
Image sizeΦ29 mm
Optical distortion–0.34%
Magnification range0.143 x to 0.001 x
Working distance range150 mm to inf mm
Mechanical
Iris controlManual
Focus controlManual
Filter threadM58 × P0.75
MountM42 × P1
Flange back length12 mm
DimensionΦ60 mm × 96.68 mm (Φ2.4" × 3.8")
Weight501 g (1.1 Ib.)
Temperature–10 °C to 50 °C (14 °F to 122 °F)
General
CertificationRoHS2.0
