Hikrobot MVL-AF5028M-M42A

Hikrobot MVL-AF5028M-M42A

Hikrobot MVL-AF5028M-M42A — An industrial machine-vision lens — sharp, low-distortion imaging for inspection and measurement. Genuine product, supplied by ZTEC.

0.00 € 0.00 €
kr 0.00
(Tax excluded)
Contact Us
OFFICIAL HIKROBOT PARTNERCE · EU compliant

Hikrobot MVL-AF5028M-M42A

FA Lens

Order code
MVL-AF5028M-M42A
Order number
310102068
Working distance
200 mm to inf mm (tolerance: ±5 mm)
Focal length
50 mm

Hikrobot MVL-AF5028M-M42A is an industrial machine-vision lens — sharp, low-distortion imaging for inspection and measurement, supplied and supported by ZTEC as your Hikrobot partner in the Nordics and Baltics.

Key features

✓Adopts high-precision lens for 4k 7 μm line scan cameras.
✓Provides excellent picture sharpness consistency and low distortion.
✓Provides superior resolution at the max. aperture of F2.8.
✓Provides max. image size Φ29 mm.

Applications & Industries

What you can solve with this product:

Sharp, distortion-free imaging
Sharp, distortion-free imaging for inspection and gauging
Matched field of view and working distance
Matched field of view and working distance for the camera
Stable imaging
Stable imaging for measurement and positioning

Specifications

Performance
Focal length50 mm
F-numberF2.8 to F16
Image sizeΦ29 mm
Optical distortion0.05%
Magnification range0.267 x to 0.001 x
Working distance range200 mm to inf mm (tolerance: ±5 mm)
Mechanical
Iris controlManual
Focus controlManual
Filter threadM46 × P0.75
MountM42 × P1
Flange back length12 mm
DimensionΦ50 mm × 73.2 mm (Φ2.0" × 2.9")
Temperature–10 °C to 50 °C (14 °F to 122 °F)
General
CertificationRoHS 2.0
