Hikrobot MVL-LF6040M-013-M72

Hikrobot MVL-LF6040M-013-M72

Hikrobot MVL-LF6040M-013-M72 — An industrial machine-vision lens — sharp, low-distortion imaging for inspection and measurement. Genuine product, supplied by ZTEC.

0.00 € 0.00 €
kr 0.00
(Tax excluded)
Contact Us
OFFICIAL HIKROBOT PARTNERCE · EU compliant

Hikrobot MVL-LF6040M-013-M72

FA Lens

Order code
MVL-LF6040M-013-M72
Order number
310102151
Working distance
200 mm to 900 mm (tolerance: ±5 mm)
Focal length
60 mm

Hikrobot MVL-LF6040M-013-M72 is an industrial machine-vision lens — sharp, low-distortion imaging for inspection and measurement, supplied and supported by ZTEC as your Hikrobot partner in the Nordics and Baltics.

Key features

✓Adopts high-precision lens for 8k 7 μm line scan cameras.
✓Provides excellent picture sharpness consistency, low distortion.
✓Provides superior resolution at maximum aperture of F4.
✓Provides maximum image size Ø58 mm.

Applications & Industries

What you can solve with this product:

Sharp, distortion-free imaging
Sharp, distortion-free imaging for inspection and gauging
Matched field of view and working distance
Matched field of view and working distance for the camera
Stable imaging
Stable imaging for measurement and positioning

Specifications

Performance
Focal length60 mm
F-numberF4.0 to F22
Image sizeØ58 mm
Optical distortion–0.45%
Magnification range0.07x to 0.37x
Working distance range200 mm to 900 mm (tolerance: ±5 mm)
Conjugate distance range307 mm to 990 mm (tolerance: ±9 mm)
Mechanical
Iris controlManual
Focus controlManual
Filter threadM58 × P0.75
MountM72 × P0.75
Flange back length12 mm
DimensionØ76 mm × 88.2 mm to 107.0 mm (Ø3.0'' × 3.5" to 4.2")
Weight484 g (1.1 Ib.)
Temperature–10 °C to 50 °C (14 °F to 122 °F)
General
CertificationRoHS2.0
