Hikrobot MV-GE4002
OFFICIAL HIKROBOT PARTNERCE · EU compliant

Hikrobot MV-GE4002

Frame Grabber

Order code
MV-GE4002
Order number
310102872
Interface
RJ45 × 2 RJ45 × 4

Hikrobot MV-GE4002 is a machine-vision frame grabber for high-bandwidth image transfer between industrial camera and PC.

Key features

✓Supports IEEE 802.3 protocol.
✓Supports PCI-E gen2 × 4 bus interface.
✓Adopts multiple independent 2.5 GigE ports.
✓Supports 10/100/1000/2500 Mbps network adaptation.
✓Supports jumbo frames up to 9 KB.
✓Supports 3U and 4U chassis.

Applications & Industries

What you can solve with this product:

High-bandwidth image capture (Camera Link / CoaxPress)
High-bandwidth image capture (Camera Link / CoaxPress)
Deterministic acquisition
Deterministic acquisition for high-speed inspection
Multi-camera image transfer to the vision PC
Multi-camera image transfer to the vision PC

Specifications

Host interface
InterconnectPCI-E gen2 × 4
Delivery bandwidth2000 MB/s (max. transmission bandwidth)
Camera interface
StandardIEEE 802.3
InterfaceRJ45 × 2 RJ45 × 4
Camera type supportedGigE industrial camera, 2.5 GigE industrial camera
Camera quantity supported2 at most 4 at most
Camera connection speed10/100/1000/2500 Mbps
Stream2 4
Electrical feature
Power consumption4 W, 6.3 W
Mechanical
Dimension181 mm × 126.3 mm × 21.6 mm (7.1" × 5.0" × 0.9")
WeightApprox. 182 g (0.4 lb.), Approx. 190 g (0.4 lb.)
TemperatureWorking temperature: 0 °C to 55 °C (32 °F to 131 °F) Storage temperature: –20 °C to 70 °C (–4 °F to 158 °F)
Humidity10% RH to 95% RH (no condensation)
General
Operating systemWindows 7/10/11, Ubuntu18.04 to 24.04 on 64-bit Linux
CertificationCE, RoHS, KC
