SensoPart FGL 50-RK-50-NSM4

A fork (slot) sensor with built-in emitter and receiver for precise edge, label and small-part detection in a fixed gap

Order code
FGL 50-RK-50-NSM4
Order number
832-11007
SensoPart FGL 50-RK-50-NSM4
Working distance
0
Output
NPN
Connection
Plug M8, 4-pin
Protection
IP 67

SensoPart FGL 50-RK-50-NSM4 is a fork (slot) sensor with built-in emitter and receiver for precise edge, label and small-part detection in a fixed gap, supplied and supported by ZTEC as your SensoPart partner in the Nordics and Baltics.

Key features

Fork widths: 30 … 120 mm
Small part detection from 0.2 mm
Robust metal plug connection
Sensor adjustment via teach-in and control input
Versatile mounting possibilities
N.O./N.C. switchable

Applications & Industries

What you can solve with this product:

Typical industries: Factory automationMachineryPackagingFood & beverage
Presence and completeness inspection
Presence and completeness inspection
Measurement and positioning
Measurement and positioning
Surface and print/label inspection
Surface and print/label inspection
Robot guidance and pick-and-place
Robot guidance and pick-and-place

Specifications

Specifications
SeriesOptical fork
Working distance min. [mm]0
Working distance max. [mm]50
Velocity [Hz]2000
AdjustmentTeach-in
Light sourceLED, red
Switching outputNPN
Temperature range [°C]-20 ... +60
Connection typePlug M8, 4-pin
Enclosure ratingIP 67
