Description
Supply and I/O cable for actuators and sensors

M12 socket, 12-pin, straight, 3-pin (24V, GND, Trigger)
shielded 360°
with self-locking threaded joints
suitable for robots
suitable for drag chains
IP 65, IP 67, IP 68
vibration resistant
oil resistant, acid- and alkali-resistant, ozon and UV-resistant
hydrolysis resistant, sea ​​water resistant
flame retardant, welding spark proof
recyclable
ROHS compliant
halogen-free, silicone free, LABS-free


Product data
Suitable for
VISOR®
Length [m]
20
Side A: Connector type
M12
Side A: Number of pins
12
Side A: Connector orientation
straight
Side B: Connector type
Flying leads
Number of wires
3
Shielding
shielded
Suitable for robots
Yes
Suitable for drag-chains
Yes
Category
Power supply and I/O cables
Enclosure rating
IP65

Description
Supply and I/O cable for actuators and sensors

M12 socket, 12-pin, straight, 3-pin (24V, GND, Trigger)
shielded 360°
with self-locking threaded joints
suitable for robots
suitable for drag chains
IP 65, IP 67, IP 68
vibration resistant
oil resistant, acid- and alkali-resistant, ozon and UV-resistant
hydrolysis resistant, sea ​​water resistant
flame retardant, welding spark proof
recyclable
ROHS compliant
halogen-free, silicone free, LABS-free
Product data
Suitable for
VISOR®
Length [m]
5
Side A: Connector type
M12
Side A: Number of pins
12
Side A: Connector orientation
straight
Side B: Connector type
Flying leads
Number of wires
3
Shielding
shielded
Suitable for robots
Yes
Suitable for drag-chains
Yes
Category
Power supply and I/O cables
Enclosure rating
IP65

15 … 30 mm, color sensor, spot 2 x 2 mm, teach-in, 3 x PNP N.O., plug M12 8-pin

Description
Colors are reliably detected despite fluctuating scanning distances thanks to patented optical technology
3 colors distinguishable via 3 switching outputs
Even the smallest of color differences are reliably detected
Easy teach-in of colors via Teach-in button or control line
Product data
Amount of colors
3
Sensor principle
Color sensor
Spot size [mm]
4 x 4 @ 40 mm
Series
F50 (50 x 50 x 17 mm)
Working distance min. [mm]
12
Working distance max. [mm]
32
Light source
LED, white
Switching output
PNP
Temperature range [°C]
-10 ... +55
Connection type
Plug M12, 8-pin
Enclosure rating
IP 6

Description:

Sub-miniature sensor for installation in the smallest of spaces
Bright, precise laser light spot for optimum small-part detection and simple alignment
High switching frequency for detection in even the fastest processes
User-friendly operation via electronic Teach-in button or control line
Robust, glass-fibre-reinforced plastic housings


Product data:

Sensor principle
Photoelectric through-beam sensor (sender/receiver)
Series
F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]
0
Working distance max. [mm]
4000
Velocity [Hz]
4000
Adjustment
Teach-in
Light source
Laser, red (Class 1)
Switching output
PNP
Temperature range [°C]
-20 ... +50
Connection type
Plug M5, 4-pin
Enclosure rating
IP 67

Description

Sub-miniature sensor for installation in the smallest of spaces
Bright, precise laser light spot for optimum small-part detection and simple alignment
High switching frequency for detection in even the fastest processes
User-friendly operation via electronic Teach-in button or control line
Robust, glass-fibre-reinforced plastic housings


Product data

Sensor principle
Photoelectric through-beam sensor (sender/receiver)
Series
F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]
1000
Working distance max. [mm]
4000
Velocity [Hz]
4000
Adjustment
Teach-in
Light source
Laser, red (Class 1)
Switching output
PNP
Temperature range [°C]
-20 ... +50
Connection type
Pigtail, plug M8, 3-wire, 200 mm
Enclosure rating
IP 67

Description
Sub-miniature sensor for installation in the smallest of spaces
Bright, precise laser light spot for optimum small-part detection and simple alignment
High switching frequency for detection in even the fastest processes
User-friendly operation via electronic Teach-in button or control line
Robust, glass-fibre-reinforced plastic housings
Product data
Sensor principle
Photoelectric through-beam sensor (sender/receiver)
Series
F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]
1000
Working distance max. [mm]
4000
Velocity [Hz]
4000
Adjustment
Teach-in
Light source
Laser, red (Class 1)
Switching output
NPN
Temperature range [°C]
-20 ... +50
Connection type
Pigtail, plug M8, 4-wire, 200 mm
Enclosure rating
IP 67

0 ... 3 m, receiver, laser, teach-in, PNP, pigtail 200 mm with connector M8 4-pin

Description

Sub-miniature sensor for installation in the smallest of spaces
Bright, precise laser light spot for optimum small-part detection and simple alignment
High switching frequency for detection in even the fastest processes
User-friendly operation via electronic Teach-in button or control line
Robust, glass-fibre-reinforced plastic housings


Product data

Sensor principle
Photoelectric through-beam sensor (sender/receiver)
Series
F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]
1000
Working distance max. [mm]
4000
Velocity [Hz]
4000
Adjustment
Teach-in
Light source
Laser, red (Class 1)
Switching output
NPN
Temperature range [°C]
-20 ... +50
Connection type
Cable, 4-wire, 2 m
Enclosure rating
IP 67

Description

Sub-miniature sensor for installation in the smallest of spaces
Bright, precise laser light spot for optimum small-part detection and simple alignment
High switching frequency for detection in even the fastest processes
User-friendly operation via electronic Teach-in button or control line
Robust, glass-fibre-reinforced plastic housings


Product data

Sensor principle
Photoelectric through-beam sensor (sender/receiver)
Series
F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]
1000
Working distance max. [mm]
4000
Velocity [Hz]
4000
Adjustment
Teach-in
Light source
Laser, red (Class 1)
Switching output
PNP
Temperature range [°C]
-20 ... +50
Connection type
Cable, 4-wire, 2 m
Enclosure rating
IP 67

Description

Sub-miniature sensor for installation in the smallest of spaces
Bright, precise laser light spot for optimum small-part detection and simple alignment
High switching frequency for detection in even the fastest processes
User-friendly operation via electronic Teach-in button or control line
Robust, glass-fibre-reinforced plastic housings


Product data

Sensor principle
Photoelectric through-beam sensor (sender/receiver)
Series
F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]
1000
Working distance max. [mm]
4000
Velocity [Hz]
4000
Adjustment
Teach-in
Light source
Laser, red (Class 1)
Switching output
NPN
Temperature range [°C]
-20 ... +50
Connection type
Plug M5, 4-pin
Enclosure rating
IP 67

Description

Sub-miniature sensor for installation in the smallest of spaces
Bright, precise laser light spot for optimum small-part detection and simple alignment
High switching frequency for detection in even the fastest processes
User-friendly operation via electronic Teach-in button or control line
Robust, glass-fibre-reinforced plastic housings


Product data

Sensor principle
Photoelectric through-beam sensor (sender/receiver)
Series
F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]
1000
Working distance max. [mm]
4000
Velocity [Hz]
4000
Adjustment
Teach-in
Light source
Laser, red (Class 1)
Switching output
PNP
Temperature range [°C]
-20 ... +50
Connection type
Plug M5, 4-pin
Enclosure rating
IP 67

Description

Sub-miniature sensor for installation in the smallest of spaces
Bright, precise laser light spot for optimum small-part detection and simple alignment
High switching frequency for detection in even the fastest processes
User-friendly operation via electronic Teach-in button or control line
Robust, glass-fibre-reinforced plastic housings


Product data

Sensor principle
Photoelectric through-beam sensor (sender/receiver)
Series
F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]
0
Working distance max. [mm]
4000
Velocity [Hz]
4000
Adjustment
Teach-in
Light source
Laser, red (Class 1)
Temperature range [°C]
-20 ... +50
Connection type
Pigtail, plug M8, 3-wire, 200 mm
Enclosure rating
IP 67

Description

Sub-miniature sensor for installation in the smallest of spaces
Bright, precise laser light spot for optimum small-part detection and simple alignment
High switching frequency for detection in even the fastest processes
User-friendly operation via electronic Teach-in button or control line
Robust, glass-fibre-reinforced plastic housings

Product data
Sensor principle
Photoelectric through-beam sensor (sender/receiver)
Series
F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]
0
Working distance max. [mm]
4000
Velocity [Hz]
4000
Adjustment
Teach-in
Light source
Laser, red (Class 1)
Temperature range [°C]
-20 ... +50
Connection type
Plug M5, 4-pin
Enclosure rating
IP 67

0 ... 3 m, emitter, laser, cable 2 m 4-wire

Description
• Sub-miniature sensor for installation in the smallest of spaces
• Bright, precise laser light spot for optimum small-part detection and simple alignment
• High switching frequency for detection in even the fastest processes
• User-friendly operation via electronic Teach-in button or control line
• Robust, glass-fibre-reinforced plastic housings

Product data
Sensor principle
Photoelectric through-beam sensor (sender/receiver)
Series
F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]
0
Working distance max. [mm]
4000
Velocity [Hz]
4000
Adjustment
Teach-in
Light source
Laser, red (Class 1)
Temperature range [°C]
-20 ... +50
Connection type
Plug M5, 4-pin
Enclosure rating
IP 67

Description
• Sub-miniature sensor for installation in the smallest of spaces
• Bright, precise laser light spot for optimum small-part detection and simple alignment
• Suitable for numerous different reflectors
• User-friendly operation via electronic Teach-in button or control line
• Robust, glass-fibre-reinforced plastic housings

Product data
Sensor principle
Photoelectric retro-reflective sensor
Spot size [mm]
1 x 3
Series
F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]
100
Working distance max. [mm]
3000
Velocity [Hz]
1000
Adjustment
Teach-in
Light source
Laser, red (Class 1)
Switching output
NPN
Temperature range [°C]
-20 ... +50
Connection type
Pigtail, plug M8, 3-wire, 200 mm
Enclosure rating
IP 67

Description
Sub-miniature sensor for installation in the smallest of spaces
Bright, precise laser light spot for optimum small-part detection and simple alignment
Suitable for numerous different reflectors
User-friendly operation via electronic Teach-in button or control line
Robust, glass-fibre-reinforced plastic housings


Product data
Sensor principle
Photoelectric retro-reflective sensor
Spot size [mm]
1 x 3
Series
F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]
100
Working distance max. [mm]
3000
Velocity [Hz]
1000
Adjustment
Teach-in
Light source
Laser, red (Class 1)
Switching output
PNP
Temperature range [°C]
-20 ... +50
Connection type
Pigtail, plug M8, 3-wire, 200 mm
Enclosure rating
IP 67

Description
• Sub-miniature sensor for installation in the smallest of spaces
• Bright, precise laser light spot for optimum small-part detection and simple alignment
• Suitable for numerous different reflectors
• User-friendly operation via electronic Teach-in button or control line
• Robust, glass-fibre-reinforced plastic housings

Product data
Sensor principle
Photoelectric retro-reflective sensor
Spot size [mm]
1 x 3
Series
F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]
100
Working distance max. [mm]
3000
Velocity [Hz]
1000
Adjustment
Teach-in
Light source
Laser, red (Class 1)
Switching output
NPN
Temperature range [°C]
-20 ... +50
Connection type
Pigtail, plug M8, 4-wire, 200 mm
Enclosure rating
IP 67

Description
• Sub-miniature sensor for installation in the smallest of spaces
• Bright, precise laser light spot for optimum small-part detection and simple alignment
• Suitable for numerous different reflectors
• User-friendly operation via electronic Teach-in button or control line
• Robust, glass-fibre-reinforced plastic housings

Product data
Sensor principle
Photoelectric retro-reflective sensor
Spot size [mm]
1 x 3
Series
F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]
100
Working distance max. [mm]
3000
Velocity [Hz]
1000
Adjustment
Teach-in
Light source
Laser, red (Class 1)
Switching output
NPN
Temperature range [°C]
-20 ... +50
Connection type
Cable, 4-wire, 2 m
Enclosure rating
IP 67
