SENSOPART FT 25-RLH-PS-M4

SensoPart FT 25-RLH-PS-M4 — Laser proximity switch bgs, red light, teach-in (button and input), 24 VDC, PNP, N.O./N.C., plug M8 4-pin For this prodcut a ne. Genuine product, supplied and supported by ZTEC.

270.00 € 270.00 €
kr 2,018.17
(Tax excluded)
Contact Us
Documents
SENSOPART FT 25-RLH-PS-M4 - Brochure 2.pdf SENSOPART FT 25-RLH-PS-M4 - Brochure.pdf SENSOPART FT 25-RLH-PS-M4 - CAD.zip SENSOPART FT 25-RLH-PS-M4 - Datasheet.pdf SENSOPART FT 25-RLH-PS-M4 - Manual.pdf
OFFICIAL SENSOPART PARTNER · ZTECCE · EU compliant

SensoPart FT 25-RLH-PS-M4

A photoelectric proximity sensor with background suppression — it detects an object at a defined range and reliably ignores whatever is behind it

Order code
FT 25-RLH-PS-M4
Order number
609-11005
SensoPart FT 25-RLH-PS-M4
Working distance
4
Output
PNP
Connection
Plug M8, 4-pin
Protection
IP69K

SensoPart FT 25-RLH-PS-M4 is a photoelectric proximity sensor with background suppression — it detects an object at a defined range and reliably ignores whatever is behind it, supplied and supported by ZTEC as your SensoPart partner in the Nordics and Baltics.

Key features

✓Precisely adjustable background suppression
✓Reliable switching despite varying object colours and surfaces
✓Reliable operation even with highly reflective backgrounds, thanks to SensoPart ASIC technology
✓Particularly suitable for the detection of the smallest of objects
✓Simple alignment thanks to easily visible light spot
✓Robust glass-fibre-reinforced plastic housings

Applications & Industries

What you can solve with this product:

Typical industries: Factory automationMachineryPackagingFood & beverage
Presence and completeness inspection
Presence and completeness inspection
Measurement and positioning
Measurement and positioning
Surface and print/label inspection
Surface and print/label inspection
Robot guidance and pick-and-place
Robot guidance and pick-and-place

Specifications

Optical data
AdjustmentTeach-in
Working distance min. [mm]4
Working distance max. [mm]120
Light sourceLaser, red (Class 1)
Electrical data
Switching outputPNP
Velocity [Hz]1000
Mechanical data
Enclosure ratingIP69K
SeriesF25 (34 x 20 x 12 mm)
Temperature range [°C]-20 ... +60
Connection typePlug M8, 4-pin
Additional specifications
Sensor principlePhotoelectric diffuse sensor with Background Suppression
