FT 55-BH-NS-L4 Description Long scanning distance of 1.2 m BlueLight technology with precisely adjustable background suppression – reliable operation even with highly reflective and glossy backgrounds Precise scanning distance adjustment by means of potentiometer • Reliable detection of highly transparent or strongly light absorbing objects Reliable detection even with angles of up to 90° Product data Sensor principle: Photoelectric diffuse sensor with Background Suppression Series: F55 (50 x 50,1 x 23 mm) Working distance min. [mm]: 3 Working distance max. [mm]: 1200 Velocity [Hz] 600 Adjustment: Potentiometer Light source: LED, blue Switching output :NPN Temperature range [°C] :-20 ... +60 Connection type: Plug M12, 4-pin Enclosure rating : IP69K, IP 67 You need to login to see your price! 0.0 EUR	FT 25-BH-PNSL-KL4 Description Miniature sensor with BlueLight technology and precisely adjustable background suppression Reliable switching with strongly light absorbing and shiny objects Reliable operation even with highly reflective backgrounds thanks to SensoPart ASIC technology Simple alignment thanks to easily visible light spot Sensor setting via teach-in, control input and IO-Link Robust glass-fibre-reinforced plastic housings Product data Sensor principle: Photoelectric diffuse sensor with Background Suppression SeriesF25 (34 x 20 x 12 mm) Working distance min. [mm] 0 Working distance max. [mm] 200 Velocity [Hz]700 Interface IO-Link Adjustment Teach-in Light source LED, blue Switching output PNP/NPN (auto detect) Temperature range [°C] -20 ... +60 Connection type Pigtail, plug M12, 4-wire, 150 mm Enclosure rating IP69K You need to login to see your price! 0.0 EUR	FT 55-CM-4-PNSDL-L4M Description Stable processes thanks to intelligent color detection, regardless of distance Economical solutions through up to twelve storable colors or jobs Dependable switching behaviour through reliable glare suppression (depending on model) Intuitive sensor setup with integrated LCD display Customised adjustment to applications through digital color value output using IO-Link Product data: Velocity [Hz]: 3000 Amount of colors: 1 Sensor principle: Color sensor Spot size [mm]: 8 x 8 Series: F55 (50 x 50,1 x 23 mm) Working distance min. [mm]: 20 Working distance max. [mm]: 150 Interface: IO-Link Light source: LED, white Switching output: PNP/NPN (auto detect) Temperature range [°C]: -10 ... +55 Connection type: Metal plug M12, 4-pin Enclosure rating: IP 67, IP69 You need to login to see your price! 0.0 EUR
FT 55-CM-4-PNSDL-L5M Description Stable processes thanks to intelligent color detection, regardless of distance Economical solutions through up to twelve storable colors or jobs Dependable switching behaviour through reliable glare suppression (depending on model) Intuitive sensor setup with integrated LCD display Customised adjustment to applications through digital color value output using IO-Link Product data: Velocity [Hz]: 3000 Amount of colors: 7 Sensor principle: Color sensor Spot size [mm]: 8 x 8 Series: F55 (50 x 50,1 x 23 mm) Working distance min. [mm]: 20 Working distance max. [mm]: 150 Interface: IO-Link Light source: LED, white Switching output: PNP/NPN (auto detect) Temperature range [°C]: -10 ... +55 Connection type: Metal plug M12, 5-pin Enclosure rating: IP 67, IP69 You need to login to see your price! 0.0 EUR	FT 55-CM-4-PNSD-L8M Description Stable processes thanks to intelligent color detection, regardless of distance Economical solutions through up to twelve storable colors or jobs Dependable switching behaviour through reliable glare suppression (depending on model) Intuitive sensor setup with integrated LCD display Customised adjustment to applications through digital color value output using IO-Link Product data: Velocity [Hz]: 3000 Amount of colors: 12 Sensor principle: Color sensor Spot size [mm]: 8 x 8 Series: F55 (50 x 50,1 x 23 mm) Working distance min. [mm]: 20 Working distance max. [mm]: 150 Light source: LED, white Switching output: PNP/NPN (auto detect) Temperature range [°C]: -10 ... +55 Connection type: Metal plug M12, 8-pin Enclosure rating: IP 67, IP69 You need to login to see your price! 0.0 EUR	FT 55-CM-3-PNSDL-L4M Description Stable processes thanks to intelligent color detection, regardless of distance Economical solutions through up to twelve storable colors or jobs Dependable switching behaviour through reliable glare suppression (depending on model) Intuitive sensor setup with integrated LCD display Customised adjustment to applications through digital color value output using IO-Link Product data: Velocity [Hz]: 3000 Amount of colors: 1 Sensor principle: Color sensor Spot size [mm]: 4 x 4 @ 40 mm Series: F55 (50 x 50,1 x 23 mm) Working distance min. [mm]: 18 Working distance max. [mm]: 60 Interface: IO-Link Light source: LED, white Switching output: PNP/NPN (auto detect) Temperature range [°C]: -10 ... +55 Connection type: Metal plug M12, 4-pin Enclosure rating: IP 67, IP69 You need to login to see your price! 0.0 EUR
FT 55-CM-3-PNSDL-L5M Description Stable processes thanks to intelligent color detection, regardless of distance Economical solutions through up to twelve storable colors or jobs Dependable switching behaviour through reliable glare suppression (depending on model) Intuitive sensor setup with integrated LCD display Customised adjustment to applications through digital color value output using IO-Link Product data: Velocity [Hz]: 3000 Amount of colors: 7 Sensor principle: Color sensor Spot size [mm]: 4 x 4 @ 40 mm Series: F55 (50 x 50,1 x 23 mm) Working distance min. [mm]: 18 Working distance max. [mm]: 60 Interface: IO-Link Light source: LED, white Switching output: PNP/NPN (auto detect) Temperature range [°C]: -10 ... +55 Connection type: Metal plug M12, 5-pin Enclosure rating: IP 67, IP69 You need to login to see your price! 0.0 EUR	FT 55-CM-3-PNSD-L8M Description Stable processes thanks to intelligent color detection, regardless of distance Economical solutions through up to twelve storable colors or jobs Dependable switching behaviour through reliable glare suppression (depending on model) Intuitive sensor setup with integrated LCD display Customised adjustment to applications through digital color value output using IO- Product data: Velocity [Hz]: 3000 Amount of colors: 12 Sensor principle: Color sensor Spot size [mm]: 4 x 4 @ 40 mm Series: F55 (50 x 50,1 x 23 mm) Working distance min. [mm]: 18 Working distance max. [mm]: 60 Light source: LED, white Switching output: PNP/NPN (auto detect) Temperature range [°C]: -10 ... +55 Connection type: Metal plug M12, 8-pin Enclosure rating: IP 67, IP69 You need to login to see your price! 0.0 EUR	FT 55-CM-1-PNSDL-L5M Description Stable processes thanks to intelligent color detection, regardless of distance Economical solutions through up to twelve storable colors or jobs Dependable switching behaviour through reliable glare suppression (depending on model) Intuitive sensor setup with integrated LCD display Customised adjustment to applications through digital color value output using IO-Link Product data: Velocity [Hz]: 500 Amount of colors: 7 Sensor principle: Color sensor Spot size [mm]: 6 x 6 Series: F55 (50 x 50,1 x 23 mm) Working distance min. [mm]: 18 Working distance max. [mm]: 32 Interface: IO-Link Light source: LED, white Switching output: PNP/NPN (auto detect) Temperature range [°C]: -10 ... +55 Connection type: Metal plug M12, 5-pin Enclosure rating: IP 67, IP69 You need to login to see your price! 0.0 EUR
FT 55-BH-PS-L4 Description Long scanning distance of 1.2 m BlueLight technology with precisely adjustable background suppression – reliable operation even with highly reflective and glossy backgrounds Precise scanning distance adjustment by means of potentiometer • Reliable detection of highly transparent or strongly lightabsorbing objects Reliable detection even with angles of up to 90° Product data Sensor principle: Photoelectric diffuse sensor with Background Suppression Series: F55 (50 x 50,1 x 23 mm) Working distance min. [mm]: 3 Working distance max. [mm]: 1200 Velocity [Hz] 600 Adjustment: Potentiometer Light source: LED, blue Switching output :PNP Temperature range [°C] :-20 ... +60 Connection type: Plug M12, 4-pin Enclosure rating : IP69K, IP 67 You need to login to see your price! 0.0 EUR	FT 50 C-3-PSL5 Description Colors are reliably detected despite fluctuating scanning distances thanks to patented optical technology Very good depth of field Very simple setup (via button and control line) Even the smallest of color differences are reliably detected due to pulsed white light Varying light spot sizes depending on task Product data: Amount of colors: 1 Sensor principle: Color sensor Spot size [mm]: 4 x 4 @ 40 mm Series: F50 (50 x 50 x 17 mm) Working distance min. [mm]: 12 Working distance max. [mm]: 32 Light source: LED, white Switching output: PNP Temperature range [°C]: -10 ... +55 Connection type: Plug M12, 5-pin Enclosure rating: IP 67 You need to login to see your price! 0.0 EUR	FT 50 C-2-PSL5 Description Colors are reliably detected despite fluctuating scanning distances thanks to patented optical technology Very good depth of field Very simple setup (via button and control line) Even the smallest of color differences are reliably detected due to pulsed white light Varying light spot sizes depending on task Product data: Amount of colors: 1 Sensor principle: Color sensor Spot size [mm]: 2 x 2 @ 40 mm Series: F50 (50 x 50 x 17 mm) Working distance min. [mm]: 15 Working distance max. [mm]: 30 Light source: LED, white Switching output: PNP Temperature range [°C]: -10 ... +55 Connection type: Plug M12, 5-pin Enclosure rating: IP 67 You need to login to see your price! 0.0 EUR
FT 50 C-1-PSL5 Description Colors are reliably detected despite fluctuating scanning distances thanks to patented optical technology Very good depth of field Very simple setup (via button and control line) Even the smallest of color differences are reliably detected due to pulsed white light Varying light spot sizes depending on task Product data: Amount of colors: 1 Sensor principle: Color sensor Spot size [mm]: 4 x 4 @ 40 mm Series: F50 (50 x 50 x 17 mm) Working distance min. [mm]: 12 Working distance max. [mm]: 32 Light source: LED, white Switching output: PNP Temperature range [°C]: -10 ... +55 Connection type: Plug M12, 5-pin Enclosure rating: IP 67 You need to login to see your price! 0.0 EUR	FT 50 C-3-PSL8 Description Colors are reliably detected despite fluctuating scanning distances thanks to patented optical technology 3 colors distinguishable via 3 switching outputs Even the smallest of color differences are reliably detected Easy teach-in of colors via Teach-in button or control line Product data Amount of colors 3 Sensor principle Color sensor Spot size [mm] 4 x 4 @ 40 mm Series F50 (50 x 50 x 17 mm) Working distance min. [mm] 12 Working distance max. [mm] 32 Light source LED, white Switching output PNP Temperature range [°C] -10 ... +55 Connection type Plug M12, 8-pin Enclosure rating IP 67 You need to login to see your price! 0.0 EUR	FT 50 C-2-PSL8 Description Colors are reliably detected despite fluctuating scanning distances thanks to patented optical technology 3 colors distinguishable via 3 switching outputs Even the smallest of color differences are reliably detected Easy teach-in of colors via Teach-in button or control line Product data: Amount of colors: 3 Sensor principle: Color sensor Spot size [mm]: 4 x 4 @ 40 mm Series: F50 (50 x 50 x 17 mm) Working distance min. [mm]: 12 Working distance max. [mm]: 32 Light source: LED, white Switching output: PNP Temperature range [°C]: -10 ... +55 Connection type: Plug M12, 8-pin Enclosure rating: IP 67 You need to login to see your price! 0.0 EUR
FT 50 BH-PAL4 Description Precisely adjustable background suppression Simple scanning distance adjustment thanks to indicator scale Plug connector rotatable Product data Sensor principle: Photoelectric diffuse sensor with Background Suppression Spot size [mm]: 5 x 5 Series: F50 (50 x 50 x 17 mm) Working distance min. [mm]: 30 Working distance max. [mm]: 300 Velocity [Hz]: 1000 Adjustment: Potentiometer Light source: LED, blue Switching output: PNP/NPN, antivalent Temperature range [°C]: -20 ... +60 Connection type: Plug M12, 4-pin Enclosure rating: IP 67 You need to login to see your price! 0.0 EUR	FT 25-BH-PNSL-KM4 Description Miniature sensor with BlueLight technology and precisely adjustable background suppression Reliable switching with strongly light absorbing and shiny objects Reliable operation even with highly reflective backgrounds thanks to SensoPart ASIC technology Simple alignment thanks to easily visible light spot Sensor setting via teach-in, control input and IO-Link Robust glass-fibre-reinforced plastic housings Product data Sensor principle Photoelectric diffuse sensor with Background Suppression Series F25 (34 x 20 x 12 mm) Working distance min. [mm] 0 Working distance max. [mm] 200 Velocity [Hz] 700 Interface IO-Link Adjustment Teach-in Light source LED, blue Switching output PNP/NPN (auto detect) Temperature range [°C] -20 ... +60 Connection type Pigtail, plug M8, 4-wire, 150 mm Enclosure rating IP69K You need to login to see your price! 0.0 EUR	FT 25-BH-PNSL-M4 Description Miniature sensor with BlueLight technology and precisely adjustable background suppression Reliable switching with strongly light absorbing and shiny objects Reliable operation even with highly reflective backgrounds thanks to SensoPart ASIC technology Simple alignment thanks to easily visible light spot Sensor setting via teach-in, control input and IO-Link Robust glass-fibre-reinforced plastic housings Product data Sensor principle: Photoelectric diffuse sensor with Background Suppression Series: F25 (34 x 20 x 12 mm) Working distance min. [mm]: 0 Working distance max. [mm]: 200 Velocity [Hz]: 700 Interface: IO-Link Adjustment: Teach-in Light source: LED, blue Switching output: PNP/NPN (auto detect) Temperature range [°C]: -20 ... +60 Connection type: Plug M8, 4-pin Enclosure rating: IP69K You need to login to see your price! 0.0 EUR
FT 25-BH-PNSL-M4M Description Miniature sensor with BlueLight technology and precisely adjustable background suppression Reliable switching with strongly light absorbing and shiny objects Reliable operation even with highly reflective backgrounds thanks to SensoPart ASIC technology Simple alignment thanks to easily visible light spot Sensor setting via teach-in, control input and IO-Link Robust glass-fibre-reinforced plastic housings Product data Sensor principle: Photoelectric diffuse sensor with Background Suppression Series: F25 (34 x 20 x 12 mm) Working distance min. [mm]: 0 Working distance max. [mm]: 200 Velocity [Hz]: 700 Interface: IO-Link Adjustment: Teach-in Light source: LED, blue Switching output: PNP/NPN (auto detect) Temperature range [°C]: -20 ... +60 Connection type: Metal plug M8, 4-pin Enclosure rating: IP69K You need to login to see your price! 0.0 EUR	FT 25-BF2-PS-K4 Description Miniature sensor with BlueLight technology and high-precision, fixed background suppression Reliable switching behaviour with strongly light-absorbing and highly transparent objects Functions reliably without reflector - even with critical object surfaces Tamper-proof sensor version - no adjustment possible Robust, glass-fibre reinforced plastic housing Simple fixation and alignment through innovative dovetail mounting concept Product data Sensor principle: Photoelectric diffuse sensor with Background Suppression Series: F25 (34 x 20 x 12 mm) Working distance min. [mm]: 0 Working distance max. [mm]: 80 Velocity [Hz]: 1000 Adjustment: Control input Light source: LED, blue Switching output: PNP Temperature range [°C]: -20 ... +40 Connection type: Cable, 4-wire, 2 m Enclosure rating: IP69 You need to login to see your price! 0.0 EUR
