Description
Precise detection of the slightest of contrast differences through multi-color RGB evaluation
Very robust operation despite fluttering and glossy objects
Simple alignment thanks to very precise and easily visible light spot
Communication via 3-color light spot (simple, comprehensible, clearly defined)
Very accurate positioning due to rapid scanning rate of 10 µs

Product data:
Sensor principle: Contrast sensor
Spot size [mm]: 1 x 4
Working distance min. [mm]: 9
Working distance max. [mm]: 15
Light source: LED, RGB
Switching output: Push-pull
Temperature range [°C]: -20 ... +55
Connection type: Plug M8, 4-pin
Enclosure rating: IP 67, IP69

Description
Miniature housing with measurement ranges up to 200 mm for an easy integration and high flexibility
High linearity and high repeatability for precise control tasks
Almost surface independant detection on homogeneous object surfaces
Invertible analogue characteristic
Window mode e.g. for two-step controls separately adjustable
Measurement value output via IO-Link

Product data:
Linearity [mm]: 2
Sensor principle: Distance sensor with triangulation
Series: F25 (34 x 20 x 12 mm)
Working distance min. [mm]: 30
Working distance max. [mm]: 200
Velocity [Hz]: 1000
Interface: IO-Link
Type: Cubic
Light source: LED, red
Switching output: PNP/NPN (auto detect)
Amount of swithing outputs: 1
Resolution [mm]: 0.68
Repeatability [mm]: 1
Temperature range [°C]: -20 ... +60
Temperature drift [%]: 0,2 mm / K
Measurement output: Analog (voltage), IO-Link
Connection type: Metal plug M8, 4-pin
Enclosure rating: IP 67, IP69K

Description
Miniature housing with measurement ranges up to 200 mm for an easy integration and high flexibility
High linearity and high repeatability for precise control tasks
Almost surface independant detection on homogeneous object surfaces
Invertible analogue characteristic
Window mode e.g. for two-step controls separately adjustable
Measurement value output via IO-Link

Product data:
Linearity [mm]: 0.4
Sensor principle: Distance sensor with triangulation
Series: F25 (34 x 20 x 12 mm)
Working distance min. [mm]: 20
Working distance max. [mm]: 80
Velocity [Hz]: 1000
Interface: IO-Link
Type: Cubic
Light source: LED, red
Switching output: PNP/NPN (auto detect)
Amount of swithing outputs: 1
Resolution [mm]: 0.12
Repeatability [mm]: 0.4
Temperature range [°C]: -20 ... +60
Temperature drift [%]: 0,1 mm / K
Measurement output: Analog (voltage), IO-Link
Connection type: Metal plug M8, 4-pin
Enclosure rating: IP 67, IP69K

Description
A follow up product is available.

Miniature housing with measurement ranges up to 200 mm for an easy integration and high flexibility
High linearity and high repeatability for precise control tasks
Almost surface independant detection on homogeneous object surfaces
Invertible analogue characteristic
Window mode e.g. for two-step controls separately adjustable

Product data:
Linearity [mm]: 2
Sensor principle: Distance sensor with triangulation
Series: F25 (34 x 20 x 12 mm)
Working distance min. [mm]: 30
Working distance max. [mm]: 200
Velocity [Hz]: 1000
Type: Cubic
Light source: LED, red
Switching output: NPN, PNP/NPN (auto detect)
Amount of swithing outputs: 1
Resolution [mm]: 0.68
Repeatability [mm]: 1
Temperature range [°C]: -20 ... +60
Temperature drift [%]: 0,2 mm / K
Measurement output: Analog (voltage)
Connection type: Metal plug M8, 4-pin
Enclosure rating: IP 67, IP69K

Description
A follow up product is available.

Miniature housing with measurement ranges up to 200 mm for an easy integration and high flexibility
High linearity and high repeatability for precise control tasks
Almost surface independant detection on homogeneous object surfaces
Invertible analogue characteristic
Window mode e.g. for two-step controls separately adjustable

Product data:
Linearity [mm]: 2
Sensor principle: Distance sensor with triangulation
Series: F25 (34 x 20 x 12 mm)
Working distance min. [mm]: 30
Working distance max. [mm]: 200
Velocity [Hz]: 1000
Type: Cubic
Light source: LED, red
Switching output: PNP, PNP/NPN (auto detect)
Amount of swithing outputs: 1
Resolution [mm]: 0.68
Repeatability [mm]: 1
Temperature range [°C]: -20 ... +60
Temperature drift [%]: 0,2 mm / K
Measurement output: Analog (voltage)
Connection type: Metal plug M8, 4-pin
Enclosure rating: IP 67, IP69K

Description
A follow up product is available.

Miniature housing with measurement ranges up to 200 mm for an easy integration and high flexibility
High linearity and high repeatability for precise control tasks
Almost surface independant detection on homogeneous object surfaces
Invertible analogue characteristic
Window mode e.g. for two-step controls separately adjustable

Product data:
Linearity [mm]: 0.4
Sensor principle: Distance sensor with triangulation
Series: F25 (34 x 20 x 12 mm)
Working distance min. [mm]: 20
Working distance max. [mm]: 80
Velocity [Hz]: 1000
Type: Cubic
Light source: LED, red
Switching output: PNP, PNP/NPN (auto detect)
Amount of swithing outputs: 1
Resolution [mm]: 0.12
Repeatability [mm]: 0.4
Temperature range [°C]: -20 ... +60
Temperature drift [%]: 0,1 mm / K
Measurement output: Analog (voltage)
Connection type: Metal plug M8, 4-pin
Enclosure rating: IP 67, IP69K

A follow up product is available.

Miniature housing with measurement ranges up to 200 mm for an easy integration and high flexibility
High linearity and high repeatability for precise control tasks
Almost surface independant detection on homogeneous object surfaces
Invertible analogue characteristic
Window mode e.g. for two-step controls separately adjustable

Description
Sub-miniature sensor with BlueLight technology and precise fixed background suppression
Reliable switching behaviour with strongly light-absorbing and transparent objects, e.g. solar wafers in every process phase
Reliable operation without reflector - even with critical surfaces
Tamper-proof sensor design - no misalignment possible
Simple mounting and adjustment through innovative dovetail clamp mounting

Product data:
Sensor principle: Photoelectric diffuse sensor with Background Suppression
Series: F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]: 2
Working distance max. [mm]: 50
Velocity [Hz]: 1000
Adjustment: Control input
Light source: LED, blue
Switching output: NPN
Temperature range [°C]: -20 ... +50
Connection type: Pigtail, plug M8, 3-wire, 200 mm
Enclosure rating: IP 67

Description
Sub-miniature sensor with BlueLight technology and precise fixed background suppression
Reliable switching behaviour with strongly light-absorbing and transparent objects, e.g. solar wafers in every process phase
Reliable operation without reflector - even with critical surfaces
Tamper-proof sensor design - no misalignment possible
Simple mounting and adjustment through innovative dovetail clamp mounting
Product data
Sensor principle
Photoelectric diffuse sensor with Background Suppression
Series
F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]
2
Working distance max. [mm]
50
Velocity [Hz]
1000
Adjustment
Control input
Light source
LED, blue
Switching output
NPN
Temperature range [°C]
-20 ... +50
Connection type
Pigtail, plug M8, 4-wire, 200 mm
Enclosure rating
IP 67

Description
Sub-miniature sensor with BlueLight technology and precise fixed background suppression
Reliable switching behaviour with strongly light-absorbing and transparent objects, e.g. solar wafers in every process phase
Reliable operation without reflector - even with critical surfaces
Tamper-proof sensor design - no misalignment possible
Simple mounting and adjustment through innovative dovetail clamp mounting

Product data
Sensor principle: Photoelectric diffuse sensor with Background Suppression
Series: F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]: 2
Working distance max. [mm]: 50
Velocity [Hz]: 1000
Adjustment: Control input
Light source: LED, blue
Switching output: NPN
Temperature range [°C]: -20 ... +50
Connection type: Cable, 4-wire, 2 m
Enclosure rating: IP 67

Description
Sub-miniature sensor with BlueLight technology and precise fixed background suppression
Reliable switching behaviour with strongly light-absorbing and transparent objects, e.g. solar wafers in every process phase
Reliable operation without reflector - even with critical surfaces
Tamper-proof sensor design - no misalignment possible
Simple mounting and adjustment through innovative dovetail clamp mounting

Product data
Sensor principle: Photoelectric diffuse sensor with Background Suppression
Series: F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]: 2
Working distance max. [mm]: 50
Velocity [Hz]: 1000
Adjustment: Control input
Light source: LED, blue
Switching output: PNP
Temperature range [°C]: -20 ... +50
Connection type: Pigtail, plug M8, 3-wire, 200 mm
Enclosure rating: IP 67

2 … 50 mm, blue light, bgs, fixed focus, PNP, pigtail 200 mm with connector M8 4-pin

2 … 50 mm, blue light, bgs, fixed focus, PNP, cable 2 m 4-wire

Description
Sub-miniature sensor with BlueLight technology and precise fixed background suppression
Reliable switching behaviour with strongly light-absorbing and transparent objects, e.g. solar wafers in every process phase
Reliable operation without reflector - even with critical surfaces
Tamper-proof sensor design - no misalignment possible
Simple mounting and adjustment through innovative dovetail clamp mounting

Product data: Sensor principle
Photoelectric diffuse sensor with Background Suppression
Series: F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]: 2
Working distance max. [mm]: 30
Velocity [Hz] :1000
Adjustment: Control input
Light source: LED, blue
Switching output: NPN
Temperature range [°C]: -20 ... +50
Connection type: Pigtail, plug M8, 3-wire, 200 mm
Enclosure rating: IP 67

Description
Sub-miniature sensor with BlueLight technology and precise fixed background suppression
Reliable switching behaviour with strongly light-absorbing and transparent objects, e.g. solar wafers in every process phase
Reliable operation without reflector - even with critical surfaces
Tamper-proof sensor design - no misalignment possible
Simple mounting and adjustment through innovative dovetail clamp mounting
Product data
Sensor principle
Photoelectric diffuse sensor with Background Suppression
Series
F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]
2
Working distance max. [mm]
30
Velocity [Hz]
1000
Adjustment
Control input
Light source
LED, blue
Switching output
NPN
Temperature range [°C]
-20 ... +50
Connection type
Pigtail, plug M8, 4-wire, 200 mm
Enclosure rating
IP 67

2 … 30 mm, blue light, bgs, fixed focus, NPN, cable 2 m 4-wire

2 … 30 mm, blue light, bgs, fixed focus, PNP, pigtail 200 mm with connector M8 3-pin

Description
Sub-miniature sensor with BlueLight technology and precise fixed background suppression
Reliable switching behaviour with strongly light-absorbing and transparent objects, e.g. solar wafers in every process phase
Reliable operation without reflector - even with critical surfaces
Tamper-proof sensor design - no misalignment possible
Simple mounting and adjustment through innovative dovetail clamp mounting

Product data
Sensor principle: Photoelectric diffuse sensor with Background Suppression
Series: F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]: 2
Working distance max. [mm]: 30
Velocity [Hz]: 1000
Adjustment: Control input
Light source: LED, blue
Switching output: PNP
Temperature range [°C]: -20 ... +50
Connection type: Pigtail, plug M8, 4-wire, 200 mm
Enclosure rating: IP 67

Description
Sub-miniature sensor with BlueLight technology and precise fixed background suppression
Reliable switching behaviour with strongly light-absorbing and transparent objects, e.g. solar wafers in every process phase
Reliable operation without reflector - even with critical surfaces
Tamper-proof sensor design - no misalignment possible
Simple mounting and adjustment through innovative dovetail clamp mounting

Product data:
Sensor principle: Photoelectric diffuse sensor with Background Suppression
Series: F10 (21,1 x 14,6 x 8 mm)
Working distance min. [mm]: 2
Working distance max. [mm]: 30
Velocity [Hz]: 1000
Adjustment: Control input
Light source: LED, blue
Switching output: PNP
Temperature range [°C]: -20 ... +50
Connection type: Cable, 4-wire, 2 m
Enclosure rating: IP 67
